Laser technology


2D laser cutting

Unterschütz takes 2D laser cutting to a new level: Thanks to the latest technologies and the most precise laser control, our 2D laser products fulfil all requirements in terms of accuracy, surface quality and dimensional accuracy, helping you to achieve greater productivity and competitiveness in your industrial sector. We also provide you with reliable advice on more efficient designs and product solutions.

Our drive: Highest laser quality regardless of the material thickness and properties.

In perfection


Our solutions
for your materials

USMB's 2D laser technology impresses with its precision and bandwidth: we process a wide variety of materials such as structural steel, stainless steel and aluminium as well as a wide range of surface finishes. While we achieve maximum precision in the field of laser cutting, our plasma cutting processes are particularly suitable for thicker materials.



Get advice now



Outstanding quality
The quality of our 2D laser technology is pioneering in terms of intensity, focussing and coherence - for the cleanest cuts and precise edges.

Ideal cutting speed
The optimum cutting speed ensures efficient processing and consistent cutting quality for your materials.

Perfect maintenance
We give our all for your laser products: Continuous investment as well as careful fine-tuning and maintenance of our laser machines guarantee dimensional accuracy at the highest level.

1.100

tonnes

Laser technology with superlatives: Every year, we process more than 1,100 tonnes of steel into dimensionally accurate laser components.



About us

Portfolio


Our cutting processes

CO2 fibre

CO2 fibre

Length x width: 3,000 mm x 1,500 mm
Sheet thickness: mild steel/hardox from 20 mm; stainless steel 25 mm; aluminium 15 mm
Max. part weights: up to 2,500 kg

High Speed Cutting - High flexibility for large series and spontaneous customer orders.

Oxyfuel/plasma cutting

Oxyfuel/plasma cutting

Length × width: 3,000 × 1,500 mm
Sheet thickness: up to 160 mm
Max. part weights: up to 2,500 kg
Processing grades: steel, stainless steel, aluminium

High Speed Cutting - High flexibility for large series and spontaneous customer orders.



Overview


Our machines

Oxyfuel cutting system

Oxyfuel cutting system

max. workpiece dimensions: 3,000 mm × 1,500 mm
max. workpiece weight: 2,500 kg
max. wall thickness: 160 mm

ByStar 3015 CO2 - 4.4 kW

ByStar 3015 CO2 - 4.4 kW

Power: 4.4 kW
Max. workpiece dimensions: 3,000 mm × 1,500 mm
Max. wall thickness: stainless steel 20 mm, mild steel 20 mm, aluminium 12 mm

ByStar Fibre 3015 CO2 - 6 kW

ByStar Fibre 3015 CO2 - 6 kW

Power: 6 kW
Max. workpiece dimensions: 3,000 mm × 1,500 mm
Max. wall thickness: stainless steel 25 mm, mild steel 20 mm, aluminium 15 mm

ByStar 3015 CO2 - 6 kW

ByStar 3015 CO2 - 6 kW

Power: 6 kW
Max. workpiece dimensions: 3,000 mm × 1,500 mm
Max. wall thickness: stainless steel 25 mm, mild steel 25 mm, aluminium 15 mm

Planning & Service


Our quality promise

The Unterschütz quality promise: Comprehensive advice and planning

Comprehensive advice and planning for 100% customised products

Everything from a single source: production, assembly and commissioning of all machines and systems

Complete production from a single source

Perfect customer service: 24/7 for the best service for your machines and systems

Comprehensive personalised customer service from our employees
